Name: Barcode Scanner NEWLAND NLS-HR2081-LITE-SPM
Brand: NEWLAND
SKU: 3000000181440
Price: 1390.00 THB
Availability: InStock

NEWLAND

ซื้อ Barcode Scanner NEWLAND NLS-HR2081-LITE-SPM ที่ Mercular เพื่อนสนุกทุก Hobby ของแท้ ประกันศูนย์ไทย ส่งฟรี โปรโมชั่นเด็ด

Barcode Scanner NEWLAND NLS-HR2081-LITE-SPM

ส่งฟรี

ประกันศูนย์

ของแท้ 100%

<table border="1" cellpadding="8" cellspacing="0"><thead><tr><th>คุณสมบัติ</th><th>รายละเอียด</th></tr></thead><tbody><tr><td>Brand</td><td>NEWLAND</td></tr><tr><td>Model</td><td>NLS-HR2081-LITE-SPM</td></tr><tr><td>Support Barcode Type</td><td>1D, 2D</td></tr><tr><td>Interface</td><td>USB</td></tr><tr><td>Light Source</td><td>Illumination : White LED
Aiming : Red LED (625nm)</td></tr><tr><td>Sensor Resolution</td><td>640 x 480 CMOS
&ge;3mil</td></tr><tr><td>Scan Rate</td><td>60 fps</td></tr><tr><td>Scan Angle</td><td>Pitch: &plusmn;55&deg;, Skew: &plusmn;55&deg;, Roll: 360&deg;</td></tr><tr><td>Field of View</td><td>Horizontal 45&deg;, Vertical 34&deg;</td></tr><tr><td>Depth of Field</td><td>EAN-13 : 50mm-260mm (13mil)
Code 39 : 50mm-115mm (5mil)
PDF 417 : 50mm-120mm (6.7mil)
Data Matrix : 35mm-125mm (10mil)
QR Code : 30mm-170mm (15mil)</td></tr><tr><td>PCS</td><td>20%</td></tr><tr><td>Support Symbol</td><td>1D : Code 11, Code 128, Code 39, GS1-128 (UCC/EAN 128), AIM 128, ISBT 128, Codabar, Code 93, UPC-A, UPC-E, Coupon, GS1 Composite, EAN-8, EAN-13, ISBN/ISSN, Interleaved 2 of 5, Matrix 2 of 5, Industrial 25, ITF6, ITF-14, Standard 25, China Post 25, MSI Plessey, Plessey, GS1 Databar (RSS).

2D :&nbsp;PDF417, Micro PDF417, Micro QR, QR Code, Data Matrix, Aztec.</td></tr><tr><td>Trigger Mode</td><td>Handheld / Continuous / Auto-Induction</td></tr><tr><td>Sensor</td><td>Beep, LED</td></tr><tr><td>Power Supply</td><td>Operating Voltage : 5VDC&plusmn;5%
Rated Power Consumption : 950mW (typical)
Current@5VDC : Operating: 190mA (typical), 201mA (max.), Idle: 35mA</td></tr><tr><td>Enviroment</td><td>Operating Temperature : -20&deg;C to 60&deg;C (-4&deg;F to 140&deg;F)
Storage Temperature : -40&deg;C to 70&deg;C (-40&deg;F to 158&deg;F)
Humidity : 5%~95% (non-condensing)
ESD : &plusmn;15 KV (air discharge); &plusmn;8 KV (direct discharge)
Drop : 1.2m
Sealing : IP42</td></tr><tr><td>Special Features</td><td>N/A</td></tr><tr><td>Package Contents</td><td>N/A</td></tr><tr><td>Dimension (cm)</td><td>(W x L x H) : 6.80 x 10.10 x 14.50 cm</td></tr><tr><td>Package Dimension (cm)</td><td>(W x L x H) : 8.50 x 20.50 x 10.50 cm</td></tr><tr><td>Net Weight (kg)</td><td>0.11 kg</td></tr><tr><td>Gross Weight (kg)</td><td>0.43 kg</td></tr><tr><td>Volume (cm³)</td><td>1,829.63 kg</td></tr></tbody></table>
